CASE
|
|
|
|
1U 19" Rack Mounting (W:482 X H:44 x D:270 mm). Steel chassis.
|
|
|
|
|
|
|
|
|
|
|
|
POWER
|
|
|
|
85V-260V mains, 50/60Hz. 4W max.
|
|
|
|
|
|
|
|
|
|
|
|
FRONT PANEL
|
|
|
|
|
|
|
 |
|||
|
|
|
|
|
Power
|
On/Off switch
|
|
|
Status Indicator
|
LED
|
|
|
MIDI Connections
|
DIN 41524 circular metal locking type
In A, Out A, In B, Out B (paralleled with rear panel) |
|
|
|
|
|
|
|
|
|
|
REAR PANEL
|
|
|
|
|
|
|
 |
|||
|
|
|
|
|
MIDI Connections
|
DIN 41524 circular metal locking type
In A, Out A, In B, Out B |
|
|
Long Haul Connections
|
Two XLR3M (outputs) and two XLR3F (inputs)
Out A, In A, Out B, In B |
|
|
Mains
|
IEC fused, filtered inlet
|
|
|
Earth
|
M5 bolt
|
|
|
|
|
|
|
|
|
|
|
ELECTRICAL
|
|
|
|
Long Haul Cable Type
|
Audio grade screened twisted pair, 80-90 ohms/km.
|
|
|
Maximum Length
|
>1000 metres, tested to 100 ohms per conductor.
|
|
|
Output Signal
|
0 to +5V max. complimentary @ 31.25kHz.
|
|
|
Delay
|
0.5 microseconds @ 100 metres.
11.0 microseconds @ 1000 metres. |
|
|
Pulse Width Distortion
|
< 1.0%
|
|
|
|
|
|
|
|
|
|
|
 |
|
|
|
|
|
|
This product is discontinued, but has been replaced with the Hinton Instruments Z2 which has the same functionality. More information on Z2 is available here:
http://www.hinton-instruments.co.uk/www/pmprod/longhaul/z2.htm
